201/201L Stainless steel pipe

    201/201L Stainless steel pipe

    201 stainless steel pipes are a cost-effective and versatile solution for a wide range of applications. As an austenitic chromium-nickel-manganese alloy, they offer a excellent combination of corrosion resistance, formability, and strength. These pipes are an ideal alternative to traditional 300 series stainless steels for projects where budget constraints are a key consideration, without significantly compromising on performance and aesthetics.
  • Share:
  • Contact us Inquiry

201 Stainless steel pipes are a cost-effective and versatile solution for a wide range of applications. As an austenitic chromium-nickel-manganese alloy, they offer a excellent combination of corrosion resistance, formability, and strength. These pipes are an ideal alternative to traditional 300 series stainless steels for projects where budget constraints are a key consideration, without significantly compromising on performance and aesthetics.

Product Name

201/201L Stainless steel pipe

Standard

JIS, AISI, ASTM, GB,DIN, EN, etc.

Material

201/201L

Surface

black painted, anti rust varnished, PE coated, anti rust oiled, galvanized, checkered, color coated

Outside  diameter

6mm-426mm, or as customer's requirement

Length

1m-12m, or as customer's requirement

Wall thickness

0.5mm-10mm or customer's requirement

Technical Methods

Hot Rolled, Cold rolled

Packing

Standard Seaworthy Packing, according to customer required

MOQ

1 Ton, more quantity price will be lower

Key Features & Benefits:

  • Good Corrosion Resistance: Performs well in mild atmospheric and freshwater environments. The presence of manganese and nitrogen enhances resistance to various corrosive elements compared to conventional chromium-nickel steels.

  • High Strength & Excellent Durability: Offers good mechanical properties, including notable yield strength and tensile strength, ensuring structural integrity and long service life.

  • Superior Formability and Weldability: Easy to fabricate, bend, and weld using standard methods, making them suitable for complex architectural and structural designs.

  • Attractive Appearance: Features a bright, clean, and modern surface finish that is easy to clean and maintain, making it perfect for both functional and decorative applications.

  • Cost-Effectiveness: With a lower nickel content, 201 stainless steel provides a more economical option while still delivering the essential qualities of stainless steel.

Technical Specifications (Typical):

  • Grade: UNS S20100, AISI 201

  • Chemical Composition (Typical %):

    • Chromium (Cr): 16.00 - 18.00

    • Nickel (Ni): 3.50 - 5.50

    • Manganese (Mn): 5.50 - 7.50

    • Nitrogen (N): ≤ 0.25

    • Carbon (C): ≤ 0.15

    • Silicon (Si): ≤ 1.00

    • Phosphorus (P): ≤ 0.060

    • Sulfur (S): ≤ 0.030

    • Iron (Fe): Balance

  • Mechanical Properties (Annealed Condition):

    • Tensile Strength: ≥ 655 MPa (95 ksi)

    • Yield Strength (0.2% Offset): ≥ 310 MPa (45 ksi)

    • Elongation: ≥ 40%

    • Hardness (Brinell): ≤ 241 HB

  • Standards: ASTM A312, ASTM A554, JIS G3446, etc. (Available in various schedules and wall thicknesses).

Available Specifications:

  • Size Range: Outer Diameter (OD): ½ inch to 24 inches (or customized sizes)

  • Wall Thickness: SCH 5S to SCH 80S, or as per customer requirements.

  • Length: Random lengths, fixed lengths (up to 6/6.5 meters), or cut-to-length.

  • Surface Finish: Annealed and Pickled, Bright Annealed, Polished (Various grits).

Applications:

201 stainless steel pipes are widely used in:

  • Architecture & Construction: Handrails, balustrades, window frames, decorative trims, and interior design elements.

  • Automotive Exhaust Systems: Mufflers and tailpipes.

  • Furniture & Home Appliances: Furniture frames, kitchenware, and appliance components.

  • General Purpose Tubing: For low-pressure fluid transportation, structural supports, and frames.

  • Food and Beverage Industry: Equipment for non-critical corrosive environments.
