AH36 H-Beam

    AH36 H-Beam

    The A36 H-beam is a quintessential structural member widely used in the construction and manufacturing industries. It is defined by two key characteristics: its chemical and mechanical properties, which adhere to the ASTM A36 standard, and its shape, which resembles the letter "H" in cross-section.
  • Share:
  • Contact us Inquiry

The A36 H-beam is a quintessential structural member widely used in the construction and manufacturing industries. It is defined by two key characteristics: its chemical and mechanical properties, which adhere to the ASTM A36 standard, and its shape, which resembles the letter "H" in cross-section.

This combination of a versatile, economical steel grade and an efficient structural shape makes the A36 H-beam a fundamental building block for modern infrastructure, from skyscrapers and bridges to industrial platforms and support frames.

Product Name

H-Beam Metal Steel Profile Hot Dip Galvanized Zinc Coating 30-275g M2Gzb-40c

Standard

AISI, ASTM, DIN, JIS, GB,JIS, SUS, EN, etc.

Material

AH36

Surface

black painted, anti rust varnished, PE coated, anti rust oiled, galvaniZed, checkered, color coated

Commonly Used Size(H×B, mm)

HW 100×100,HW 150×150,HM 200×150,HM 300×200,HN 400×200,HN 500×200,or as per your request

H

100~900mm, according to customer's requirement

B

100~400mm,or as per your request

t1

5~40mm,or as per your request

t2

6~45mm,or as per your request

Technical  Methods

Hot Rolled/Cold Rolling

Packaging

According to customer required

Application

Applied in multiple fields such as architecture, bridges, machinery, energy, etc. etc.

Packing

Standard Seaworthy Packing (Plastic film in the first layer,second layer is Kraft paper. Third layer is galvanized sheet)

MOQ

1 Ton, more quantity price will be lower


Key Properties of ASTM A36 Steel

ASTM A36 is one of the most commonly used mild, low-carbon steels. Its properties are as follows:

High Yield Strength: It has a minimum yield strength of 36,000 psi (250 MPa), which is the stress point at which it begins to deform permanently. The "36" in its name derives from this property.

Good Tensile Strength: It has a tensile strength of 58-80,000 psi (400-550 MPa), which is its resistance to breaking under tension.

Excellent Weldability and Machinability: The low carbon content makes A36 steel exceptionally easy to weld, cut, drill, and form with standard methods without requiring pre- or post-heating treatments in most cases.

Ductility: It exhibits good ductility, allowing it to bend and deform significantly before fracturing, which is a critical safety feature in structures that experience high stress or seismic activity.

Availability and Cost-Effectiveness: Its widespread production makes it readily available and one of the most economical choices for a vast range of projects.

The H-Beam (Wide Flange) Shape

The "H-beam" shape, more accurately called a "Wide Flange Beam" (W-beam) in engineering contexts, is defined by its three integral parts:

Flanges: The two horizontal, parallel elements. They are wider than the flanges on a standard I-beam, providing superior resistance to bending.

Web: The vertical element that connects the two flanges. It primarily resists shear forces.

The "H" Profile: This design efficiently distributes the material away from the neutral axis (the center of the cross-section), maximizing the beam's Moment of Inertia. This results in an exceptional strength-to-weight ratio, meaning it can support very heavy loads without being excessively heavy itself.

Common Applications

Due to its strength and versatility, A36 H-beams are used in a multitude of applications:

Structural Framing: As primary columns and beams in the frames of commercial buildings, industrial warehouses, and high-rise structures.

Bridge Construction: As girders and supports in bridge decks and infrastructure.

Industrial Equipment: For constructing heavy-duty frames for machinery, conveyor systems, and industrial platforms.

Truck and Trailer Beds: As the main longitudinal members (frame rails) due to their high bending resistance.

Support Columns and Piles: Used vertically to provide critical load-bearing support.

Base Plates and Foundations: To create sturdy foundations for large equipment and structures.

Related tags: AH36 H-beam H-Beam AH36
